IMPORTANT: Disk Copy for images (RULE: always use DiskCopy 4.2!)

Please, unless absolutely necessary, always use Disk Copy 4.2 the software itself), and not any later version, for floppy disks. It does not matter if they're 800K or 1.4MB.

ALL versions of Disk Copy 6 (except 6.0.x, which is not recommended because of its weird compression schemes, and because it was never supported by Apple), omit important data from the floppy disks.

I'm referring to the software, not just the format — use of Disk Copy 6.x in DiskCopy 4.2 "mode" doesn't count — the data is still omitted.

DART will also create good images, but I don't recommend it because its compression scheme is very obscure.

For non-floppy disks, Disk Copy 6.x is fine, though Toast also works.

Comments

2010, October 5 - 5:44pm

Offline

Joined: 2009 Aug 7

Posts:

What do you recommend for Mac OS 9.2.2? On my Mac OS 9.2.2 Disk Copy 4.2 refuses to work.

2010, October 5 - 5:54pm

Protocol 7

Offline

Joined: 2010 Aug 7

Posts:

I'm pretty sure I've used it on 9.2.2 without any trouble.

2010, October 5 - 6:31pm

Offline

Joined: 2009 Aug 7

Posts:

Okay, I'll try again. However, I fear the problem might be that my Mac does not have a built in floppy drive. I have to use an external USB floppy drive.

2010, October 5 - 6:32pm

bertyboy

Offline

Joined: 2009 Jun 14

Posts:

Do you still make images from original floppies on your Mac with OS9.2.2 ? So how is it an issue ?

2010, October 5 - 6:57pm

Protocol 7

Offline

Joined: 2010 Aug 7

Posts:

I use a USB floppy too. Perhaps some are more compatible than others. I just tried it on my iBook with 9.2.2 and it reads and writes fine.

2010, October 5 - 7:04pm

Balrog

Offline

Joined: 2009 Apr 24

Posts:

Disk Copy 4.2 with an external USB floppy drive probably will not work. Better to use Linux and 'dd' or another "raw image" creation program (I'm not sure if one exists for OS9 though), if you're stuck with one of those. In OS X, you'd do as follows in Terminal:

df (find the device name for the disk)
diskutil umount devicename (devicename is from the list generated by df)
dd if=devicename of=file.img (create the image)
and there you go. Be careful with dd, if you specify a device as of= it will overwrite the disk (unless it's physically locked)! ALWAYS LOCK YOUR DISKS!

The reason is that Disk Copy 6.3.3 not only destroys tag information, but also zeroes unallocated sectors. Why is this a problem? Because often disks were used for multiple purposes, and interesting things can exist in this unallocated space. Even source code (yes, it's been documented).

2010, October 5 - 7:26pm

SwedeBear

Offline

Joined: 2009 Apr 18

Posts:

•Protocol 7: what make/model is the drive?

2010, October 5 - 7:38pm

Protocol 7

Offline

Joined: 2010 Aug 7

Posts:

It's a combined floppy and card reader. Floppy drive just shows up as "Mitsumi USB FDD", there's no model number.

2010, October 5 - 7:58pm

#10

Balrog

Offline

Joined: 2009 Apr 24

Posts:

USB floppy drives will never work with Disk Copy 4.2. It's only designed to work with the IWM/SWIM interface in Old World Macs.

2010, October 5 - 8:17pm

#11

SwedeBear

Offline

Joined: 2009 Apr 18

Posts:

How would it work under emulation? There´s a way to boot from a (real) (USB-) floppy in BasiliskII and to some extent also manipulate a floppy in a (real) (USB-) floppy in SheepShaver, so could it be made with Disk Copy 4.2 under emulation?

2010, October 5 - 8:23pm

#12

Balrog

Offline

Joined: 2009 Apr 24

Posts:

There isn't any need to, if you use a "raw" imaging utility like dd in Linux/OS X or something similar in Windows. Zip it immediately afterwards. I'll test a few utilities and respond with results.

2010, October 5 - 8:24pm

#13

Vitoarc

Offline

Joined: 2010 Aug 15

Posts:

SweedeBear if you know some trick to get a USB floppy to be recognized in Basiliskll please share it.

The official word that I've seen from Emaculation is that it's not possible.

2010, October 5 - 8:26pm

#14

Balrog

Offline

Joined: 2009 Apr 24

Posts:

Disk Charmer is also good.

EDIT: Yes, this one does create proper images.

2010, October 6 - 2:11am

(Reply to #13) #15

MikeTomTom

Offline

Joined: 2009 Dec 7

Posts:

@Vitoarc asked:

SweedeBear if you know some trick to get a USB floppy to be recognized in Basiliskll please share it. - The official word that I've seen from Emaculation is that it's not possible.

Well, I know how I use a USB floppy disk drive in Basilisk II. Ironically perhaps, because I run an earlier Basilisk II port on a Windows OS!

Of the various Basilisk II's out there, I only use the now old and no longer developed "Lauri Pesonen" Windows final port 142 from 2001 in preference to newer ports. Why?:

a). It can read/write/boot floppy media via any floppy disk drive including USB - Caveat; only 1.4MB media support, a hardware limitation of Windows (and external USB) f/disk drives.

b). SCSI support, can mount read/write/boot actual SCSI HFS formatted drives (including Iomega zip). Requires SCSI hardware controllers on the Windows side tho'.

c). Full TCP/IP ethernet and AppleTalk over TCP/IP support. Can set a fixed IP address for the emulator in your Mac OS's Control Panels if desired.

d). Excellent keyboard re-mapping at hand.

Anyway I digress. Perhaps that official "not possible" you read in Emaculation could be rephrased a little tho'

2010, October 6 - 3:12am

#16

Vitoarc

Offline

Joined: 2010 Aug 15

Posts:

Perhaps that official "not possible" you read in Emaculation could be rephrased a little tho'

Here's the thread: http://www.emaculation.com/forum/viewtopic.php?t=5662&sid=9fcc7d54e9b586...

But there is a way to get it working in Windows, as you've found, and now I know...

http://www.emaculation.com/forum/viewtopic.php?t=5853&sid=e4a61ac48bd2cc...

By the way Mike. I'd really appreciate it, if it's possible, if you could please upload Virex 6x so that it can be used along with the latest definitions (through 2007 I believe was the last update).

2010, October 6 - 4:47am

(Reply to #16) #17

MikeTomTom

Offline

Joined: 2009 Dec 7

Posts:

@Vitoarc:

there is a way to get it working in Windows, as you've found

Yes, though in that last forum link there was no mention of which Basilisk II port they were using. With the Lauri Pesonen 142 port it seems to be even easier than mentioned in those descriptions. Map whatever Windows drive numbers you want to use in the B2 Gui and tell it to detect media when inserted, then forget about it. - I dimly recall that I needed to install ASPI drivers when I used this B2 under Windows 98, but haven't needed these since Win 2K - XP - Haven't run the Lauri Pesonen port under Vista or Win 7 so don't know if it still works OK under those OS versions.

I'll put up the Virex software soon. Its version 6.1 - That last def file thats still available is for 6.2 but it works OK with 6.1, some (non critical) function has to be turned off in 6.1 to stop the alert messages.

2010, October 6 - 5:28am

(Reply to #7) #18

MikeTomTom

Offline

Joined: 2009 Dec 7

Posts:

@Balrog added:

The reason is that Disk Copy 6.3.3 not only destroys tag information, but also zeroes unallocated sectors.

There is a preference setting in Disk Copy's Preferences: "Zero Block" (on/off). Since turning this off when copying floppies - and also making certain to choose the 1.4MB or 800K floppy setting - not 1440 K or 800 K (partition size) it always defaults to, I seem to get fairly accurate copies. I could be wrong though, so perhaps you can confirm?

2010, October 6 - 5:49am

#19

Balrog

Offline

Joined: 2009 Apr 24

Posts:

If you look at the data in a hex editor, unallocated blocks are turned into blocks of zeroes. This isn't what we want -- we want that data to be preserved.

2010, October 6 - 6:46am

(Reply to #19) #20

MikeTomTom

Offline

Joined: 2009 Dec 7

Posts:

@Balrog: Yes I understand this.
What I want to know is if you turn off the "Zero Block" setting in Disk Copy 6.3 does it not stop zeroing blocks of data?

I have tested this in Disk Copy 4.2 and Disk Copy 6.3 (with Zero Block turned off); saved disk image files in Disk Copy 4.2 format using both programs by copying from mounted floppy disks.
I compared the resulting image files in HexEdit and found no differences in either. That is, I cannot detect Disk Copy 6.3 writing zeros (that aren't already present) to data blocks with that preference setting turned off. MD5sums and CRCsums are the same in both types too.

Perhaps you have found otherwise. Or I'm still looking at the wrong thing.

2010, October 6 - 7:03am

#21

SwedeBear

Offline

Joined: 2009 Apr 18

Posts:

@Vitoarc: as MikeTomTom says, the limit in which media lays in the device. I can boot BasiliskII from a floppy in my USB Y-E DATA FlashBuster, though this: http://forumbilder.se/show.aspx?iid=9a6201083456Afa79 shows the importance of knowing which machines are supported…

Here´s also a short instruction on the procedure under OS X: http://www.emaculation.com/forum/viewtopic.php?t=6245&highlight=usb+andf...
and a longer, the original also under OS X: http://www.emaculation.com/forum/viewtopic.php?t=5844&highlight=usb+andf...

IIRC you could also boot a SCSI device with an ID. I´ll dig out one 'bread chest' to check this when time permits. Alas this leaves emulation out when it comes to 800/400 kB. Unless you´re a happy owner of a 'CatWeasel'[sp?] or a LC (me).

2010, October 6 - 6:54am

#22

Balrog

Offline

Joined: 2009 Apr 24

Posts:

@MikeTomTom: I'll look into this. Even so, for 400 and 800K disks always use Disk Copy 4.2 (it stores tags which most other utilities don't).

2010, October 6 - 7:11am

#23

SwedeBear

Offline

Joined: 2009 Apr 18

Posts:

…and (can´t resist it) here´s Sheepshaver with a mounted floppy from my USB floppy drive:
http://www.ladda-upp.com/bilder/41038/ss-floppy-aware

Edit:
For the OS X user; there´s a vital difference between Tiger and Leopard when it comes to mount/dismount and control a volume. Basilisk is not affected in the same way as Sheepshaver due to differences in the code.

Virtual PC users will also be aware of this; under Leopard there´s no longer any access to real CD-ROM or floppy because of changes between Tiger and Leopard.

Under SL I have no idea.

2010, October 6 - 12:09pm

(Reply to #10) #24

MikeTomTom

Offline

Joined: 2009 Dec 7

Posts:

@Balrog notes:

USB floppy drives will never work with Disk Copy 4.2. It's only designed to work with the IWM/SWIM interface in Old World Macs.

Interesting. Disk Copy 4.2 is what does work with my USB floppy drive under Basilisk II on Windows. Whereas Disk Copy 6.3.x fails with a -39 unexpected EOD error. - Disk Copy 4.2 (and likely the B2 emulation) is a winner here

Have yet to try the drive on my QuickSilver - will probably do so shortly. The drive is a TEAC external USB floppy drive. I expect it will fail on the New World hardware, but will check.

2010, October 6 - 12:33pm

#25

Protocol 7

Offline

Joined: 2010 Aug 7

Posts:

As I mentioned earlier, I can read and write floppies just fine with Disk Copy 4.2 and a USB floppy drive. So it does appear to work.

2010, October 6 - 1:17pm

(Reply to #24) #26

MikeTomTom

Offline

Joined: 2009 Dec 7

Posts:

@MikeTomTom previous mused:

Have yet to try the drive on my QuickSilver - will probably do so shortly. The drive is a TEAC external USB floppy drive. I expect it will fail on the New World hardware, but will check.

Yes. This USB drive works well on the QuickSilver. Both Disk Copy 4.2 and 6.3 make byte perfect copies from floppy disk media mounted in the USB drive to Disk Copy 4.2 format image files. However, it is only useful for imaging 1.4MB media. My Teac USB drive does not support mounting 800K or 400K media.

Back to the Centris 660AV for me for serious data copying

2010, October 6 - 4:16pm

(Reply to #11) #27

IIGS_User

Offline

Joined: 2009 Apr 8

Posts:

How would it work under emulation?

This would be my question, too. Is it possible to create newly images (not based on real floppies) using 4.2?

I'll take a look to DiskCharmer, mentioned by Balrog.

2010, October 6 - 6:22pm

#28

Offline

Joined: 2009 Aug 7

Posts:

I can confirm Mike Tom Tom's test: TEAC external USB drive works for 1.4 MB disk images from real floppys' (file extension: .image) on a real Mac (Powerbook G3 Lombard).

I will also test your question, IIGS User (new images). Cannot test emulator, though, as I don't use one.

I can tell you so much already: Disk Copy 4.2 only works if the external drive is plugged in (no matter with or without a floppy). If not, the program refuses to work.

2010, October 6 - 8:02pm

#29

Balrog

Offline

Joined: 2009 Apr 24

Posts:

@IIGS_User:

If you're creating disk images not based on floppies, use any tool: there's no data which would be lost, to begin with. Disk Copy 6.x is fine for this purpose, as it is for imaging hard drives.

2010, October 7 - 7:30am

#30

Offline

Joined: 2009 Aug 7

Posts:

Disk Copy 4.2 does not seem to be able to create disk images out of nothing. It only seems to be able to copy real disks or disk images.

2010, October 7 - 2:25pm

#31

Vitoarc

Offline

Joined: 2010 Aug 15

Posts:

It's too bad that "Disk Copy 4.2" was not named "Floppy Disk Copy 4.2" because that's it's main function, to work with floppies. It performs this duty well.

The name "Disk Copy 6.3.3" is more generic, and the name is appropriate in my opinion since it performs other functions besides copying floppies.

The nomenclature has been a source of confusion for so many, for so long.

2010, October 7 - 3:40pm

(Reply to #29) #32

IIGS_User

Offline

Joined: 2009 Apr 8

Posts:

If you're creating disk images not based on floppies, use any tool: there's no data which would be lost, to begin with. Disk Copy 6.x is fine for this purpose, as it is for imaging hard drives.

Balrog, thanks for further explanation.

2010, October 7 - 8:20pm

#33

Balrog

Offline

Joined: 2009 Apr 24

Posts:

@IIGS_User:

Always mark such images as not from original media, to reduce confusion.

2010, December 13 - 2:25am

(Reply to #31) #34

MikeTomTom

Offline

Joined: 2009 Dec 7

Posts:

Vitoarc mentioned:

It's too bad that "Disk Copy 4.2" was not named "Floppy Disk Copy 4.2" because that's it's main function, to work with floppies. It performs this duty well.
[...]
The nomenclature has been a source of confusion for so many, for so long.

If you look at its full name (on the DC 4.2 Spashscreen) you'll see its named:
Disk Copy 3.5" Floppy Disk Duplicator, v4.2

And in DC 4.2's main UI its name changes again, to:
Apple 3.5" Disk Duplicator, v4.2

Perhaps this could've been named Disk Duplicator instead... Talk about confused

Say Vito; You about?
